sunwoda residential ess SunESS Power

All-in-One Residential ESS SunESS Power

Modular, Compact and Simple
SUNWODA INSIDE, POWER YOUR LIFE
Introducing SunESS Power, The Ultimate Solution for Reliable and Efficient Power Management
SunESS Power is an unparalleled all-in-one residential energy storage system designed to revolutionize your power management experience and meet all your power needs in a modular, compact, and simple package.

All-in-One
● Modular, Compact and Simple
● Easy Installation(30 Minutes Max)
● Flexible Battery Expansion (5kWh-40kWh)

Safe and reliable
● Short circuit protection
● Optional Arc-fault prevention (AFCI)
● Optional rapid shut-down (RSD)

Withstand 150% inrush current over 10 seconds

Support 150% oversized PV power
Support 100% 3-phase Unbalanced load
Ultra-fast switching (10ms) from On-grid to Off-grid state
Max. 12 years' warranty
Support diesel generator + heat pump (optional)
Sunwoda Inside, Power Your Life
Take One Step Closer to Energy Independence with the SunESS Power
sunwoda residential ess SunESS Power
Effortless Installation:
A Testament to Simplicity
SunESS Power offers a remarkably easy installation process, requiring a maximum of 30 minutes. Say farewell to intricate procedures and welcome a hassle-free setup.
house
Unmatched Flexibility:
Battery Expansion Redefined
With its exceptional battery expansion capability, ranging from 5kWh to an extraordinary 40kWh, the SunESS Power adapts effortlessly to meet your unique energy demands.
family
Safety and Reliability:
Our Utmost Commitment
The built-in short circuit protection and arc-fault prevention (AFCI) mechanism can further enhance the safety of your power management system. For emergency situations, the optional rapid shut-down (RSD) functionality provides swift shutdown capabilities.
sunwoda home energy storage system suness power
Unyielding Performance:
Prepared for Every Challenge
With the ability to endure 150% inrush current over 10 seconds, the SunESS Power ensures a stable power supply in the face of sudden surges.It supports 150% oversized PV power and can handle 100% of the 3-phase load effortlessly.
electricity
Seamless Transition:
On-Grid to Off-Grid in an Instant
The SunESS Power boasts an ultra-fast switching time of 10ms, effortlessly transitioning from an on-grid to an off-grid state. Your essential appliances and devices continue to operate seamlessly, ensuring continuity in critical situations
pv panel
Beyond Expectations:
Supporting Additional Power Sources
Whether you require integration with a diesel generator or a heat pump, SunESS Power seamlessly incorporates these systems, offering a comprehensive and unified power management solution.
parameter371
Understand its internal structure in detail
  • Cell type
    LFP
  • Dimensions (W/H/D) mm
    650x1190x250~650x1820x250
  • Storage temperature
    -30~+60°℃
  • Operating temperature
    -10~+50°C
  • Relative humidity
    10%~95%
  • Altitude
    <4000m
  • Cooling method
    Air cooling
  • Ingress protection
    IP65
  • Rated battery capacity
    10~30kWh
  • Max. charge and discharge power
    5~15kW
  • Total weight
    146.7~366.8kg
